Brand Name : OiD
Model Number : INR18650N20A30
Certification : Complies with BIS, KC, BSMI, CB, UL, CCC, and other international safety standards.
Place of Origin : China
MOQ : 100pcs
Price : $0.5 ~ $100.0 / pcs
Delivery Time : 3 ~ 7 days for storage
Payment Terms : TT,L/C,Western Union
Name : 30A 18650 Battery
ODM : Free custom design for packs
Battery Type : 2000mAh Rechargeable
Cathode : NMC/NCA
Industry-Leading Energy Density : 250-300Wh/kg
High Discharge Rate : 30A Continuous current
Cost-Effective & Mass-Produced : Most widely produced lithium-ion cell
Standard Design : Lightweight & Space-Efficient Design
INR18650N20A30 3.6V 2000mAh 30A 500 Cycles High-Rate 18650 Battery
Product Name
INR18650N20A30 High-Rate Rechargeable Lithium-Ion Battery
Advantages
Specifications
Parameter | Value |
Model | INR18650N20A30 |
Nominal Voltage | 3.6V |
Nominal Capacity | 2000mAh |
Dimensions (D×H) | ≤18.50mm × ≤65.30mm |
Weight | ≤45.0g |
Energy Density | 410 Wh/L (volume), 160 Wh/kg (weight) |
Internal Resistance | ≤18mΩ |
Charge Cut-off Voltage | 4.20V ±0.05V |
Discharge Cut-off Voltage | 2.50V |
Max Charging Current | 6.0A |
Max Continuous Discharge Current | 30A |
Certifications | BIS, KC, BSMI, CB, UL, CCC |
Annual Production Capacity | 10 million units |
Cycle Life
Test Condition | Cycles | Capacity Retention |
6A Charge / 10A Discharge | 500 | ≥50% |
6A Charge / 20A Discharge | 500 | ≥40% |
6A Charge / 30A Discharge | 200 | ≥70% |
Discharge Curve
Operating Temperature Range
Operation | Temperature Range |
Charging | 0°C to 50°C |
Discharging | -20°C to 75°C |
Certifications
Complies with BIS, KC, BSMI, CB, UL, CCC, and other international safety standards.
Key Features
Applications
Usage Warnings & Precautions
Storage Guidelines
Warranty & Disclaimer
![]() |
High Rate 30A 18650 Battery Rechargeable 3.6 V 2000mAh Battery Images |
